LPA SD5 10

SPECIFICATIONS

Service Flow Rate
1.5 GPM (5.67 L/min)

Rated Capacity

13,210 Gallons (50,000 L)

Operation Temperature
4 ~ 38℃ (39 ~ 100℉)

Pressure Requirements
10 ~ 100 psi (0.7 ~ 6.9 bar)

Inlet / Outlet Connection
3/8″

Electrical Connection
None required

Dimension

• Overall: 3.7″ × 12.5″

• Cartridge: Ø3.3″ × 10.7″

Weight
0.6 kg

Claim
Particle, Dust, Sand, etc.

FEATURES · BENEFITS

• Pretreatment filtration (PP, Melt Blown Type)

• Mechanically removes particles up to 5 microns

• Simple, quick, and clean replacement process

LPA CB5 10

SPECIFICATIONS

Service Flow Rate
1.5 GPM (5.67 L/min)

Rated Capacity
13,210 Gallons (50,000 L)

Operation Temperature
4 ~ 38℃ (39 ~ 100℉)

Pressure Requirements
10 ~ 100 psi (0.7 ~ 6.9 bar)

Inlet / Outlet Connection
3/8"

Electrical Connection
None required

Dimension

• Overall: 3.7″ × 12.5″

• Cartridge: Ø3.3″ × 10.7″

Weight
1.0 kg

Claim

• Chlorine

• Taste and Odor

• Particulate Class 3 (5 ~ 15 µm)

FEATURES · BENEFITS

• HNN’s carbon block is made with high-quality, high-quantity GAC, ensuring superior water quality and a higher capacity compared to competitors.

• 5-micron pore size CTO block

• Extrusion carbon manufacturing ensures consistent and stable quality

• Pre-shield technology helps prevent early clogging and extends cartridge life

• Quick-change design makes filter replacement simple and clean

LPA-CS1-10

SPECIFICATIONS

• Service Flow Rate: 1.5 GPM (5.67 L/min)

• Rated Capacity: 13,210 Gallons (50,000 L)

• Operating Temperature: 4–38℃ (39–100℉)

• Pressure Requirements: 10–100 psi (0.7–6.9 bar)

• Inlet / Outlet Connection: 3/8″

• Electrical Connection: None required

• Dimensions:

  • Overall: 3.7″ × 12.5″

  • Cartridge: Ø3.3″ × 10.7″

• Weight: 0.6 kg

• Claims:

  • Scale inhibitor

  • Reduces chlorine, taste and odor

  • Particulate Class 1 (1.0 μm)

FEATURES · BENEFITS

• Reduces impurities chemically and mechanically
• 1um pore size can remove bacteria and cyst
• Replacement method is easy quick-change.
